Isotropy Ferrite Magnet (Ba-Fe)
Outstanding cost performance!
Suitable for a variety of applications.
But the Isotropy ferrite magnet is effective when evenly distributed magnetism in every direction is necessary because it has even level magnetism power in any direction, which is the opposite of an Anisotropy ferrite magnet that is effective when magnetism is necessary in a specific direction.
An Isotropy ferrite magnet is inexpensive, so it is suitable for a variety of applications in industry, education, miscellaneous goods, etc.
Shape
 |
 |
 |
|---|---|---|
| Round shape | Ring shape | Square shape |
Isotropy Ferrite Magnet (Ba-Fe) Round Shape
| Part No. | External diameter*thickness (mm) | Weight (g) |
|---|---|---|
| MF0003 | 8φ*4 | 1 |
| MF0004 | 10φ*5 | 1.96 |
| MF0005 | 10φ*10 | 3.93 |
| MF0006 | 12φ*4 | 2.26 |
| MF0007 | 15φ*3 | 2.65 |
| MF0008 | 15φ*5 | 2.42 |
| MF0009 | 20φ*4 | 6.28 |
| MF0010 | 25φ*5 | 12.27 |
| MF0011 | 30φ*5 | 17.66 |
Isotropy Ferrite Magnet (Ba-Fe) Ring Shape
| Part No. | External Diameter*Internal Diameter*Thickness (mm) | Weight (g) |
|---|---|---|
| MF0302 | 15φ*10φ*5 | 2.46 |
| MF0304 | 38φ*9φ*5.5 | 29.42 |
Isotropy Ferrite Magnet (Ba-Fe) Square Shape
| Part No. | External Diameter*Internal Diameter*Thickness(mm) | Weight (g) |
|---|---|---|
| MF0502 | 13*8*4 | 2.08 |
| MF0503 | 20*10*4(2.5φ) | 4 |
| MF0506 | 24*10*4 | 4.8 |
| MF0507 | 25*16*4 | 8 |
